Structure analysis of injection mold

What is an injection mold? In fact, the mold used in plastic injection molding is an injection mold, and the injection mold can form a messy shape and high scale accuracy or plastic products with inserts. The injection mold is more messy and fine than other molds in terms of structure, so our usual requirements for operation and protection of products are relatively high.

Then in the production process of all can be correctly used and carefully protected, protection, for an enterprise is of great significance, because he in maintaining the normal production of an enterprise together, can also improve the efficiency of the enterprise. So how should the protection and protection of injection molds be carried out? Before this, we should first know the structure and composition of the injection mold, so that we can better protect and protect the injection mold.

About the structure and composition of injection mold, I do a brief introduction here: molding parts of injection mold. The first is to give the forming data structure, scale and shape of the parts, are generally composed of concave, punch, that is, cavity and core, as well as threaded core and insert; Guide parts for injection moulds.

The setting of the guide parts is mainly to ensure that the fixed die and the moving die can be accurately aligned when they are closed. The guide parts are composed of two parts: the guide sleeve and the guide post. Some molds are also set with the guide parts on the ejector plate, which is intended to ensure that the release organization can move smoothly and reliably. Release structure of injection mold.
